The JSLT-CG-T2-16B2 is a mid-duty double-row T-profile guideway matched to 2-strand ISO 16B-2 chain (pitch 25.4 mm — the global workhorse pitch for food, beverage, and assembly conveyors). Its 48 mm-wide base carries 2 centred chain pockets (15.8 × 3.5 mm each) machined to ISO 606 envelope tolerance, separated by 1 channel of 16.2 mm. Production-ready in 5–15 days from drawing approval.
Cross-section — all dimensions in mm. Drawn to 1:1 scale (within page width).
This is the twin-strand rail you'll see in heavy-duty European bottling and assembly plants. The 11.5 mm shoulder height gives chain plates a dedicated wear surface so they never contact a steel frame edge — the failure mode that retires chains 18 months before their L10 life. The base width is sized to common DIN 8187 sprocket centres with all 2 pockets pre-aligned; bolt the rails straight to a standard aluminium extrusion grid with no shimming.
ISO 16B-2 2-strand roller chain (pitch 25.4 mm). Compatible with all chains conforming to ISO 606 / DIN 8187 / BS 228 envelopes, including ANSI #80, BS 16B-2, JIS RC101 equivalents. Roller, plate, and pin geometry of these standards are interchangeable; the JSLT-CG-T2-16B2 guideway profile accepts any of them across all 2 parallel pockets without modification.
CNC-milled groove with R-radius transitions, surface roughness Ra ≤ 1.6 µm typical. Polished groove option available for sticky-product lines.
| JSLT Part Number | JSLT-CG-T2-16B2 |
|---|---|
| Profile Type | Type T2 — Double-Row Polymer Chain Guideway |
| Chain Standard | ISO 16B-2 / ANSI equivalent |
| Chain Pitch | 25.4 mm |
| Number of Rows | 2 |
| Base width (mm) | 47.8 mm |
| Overall height (mm) | 15.0 mm |
| Shoulder height (mm) | 11.5 mm |
| Number of chain pockets | 2 mm |
| Chain pocket width (mm) | 15.8 mm |
| Chain pocket depth (mm) | 3.5 mm |
| Number of channels | 1 mm |
| Channel width (mm) | 16.2 mm |
| Standard Lengths | 1000 / 2000 / 3000 / 4000 / 5000 / 6000 mm |
| Default Stock Length | 2000 mm |
| Custom Length | Cut to your drawing — no extra cost |
| MOQ | 1 piece (sample) — no minimum on production runs |
| Lead Time | 5–15 days from drawing approval |
All four UHMWPE grades are stocked in-house. Default for this profile is highlighted.
Send your DWG / DXF / PDF / STEP — we quote in 24 hours, MOQ 1 piece, lead time 5–15 days.
Standard hole patterns, counterbores, end chamfers, mitre cuts, and curved guide segments are all routine — no setup fee on first articles. Send a sketch, photo or full 3D STEP file and we will return a fully-quoted spec sheet within one working day.
Use the 3D preview file to validate fit in your assembly. Production files (DXF / STEP) are released after we confirm tolerances together.
